派克 FEM-371-6FB   原装现货

派克 FEM-371-6FB   原装现货

parker快速接头，Parker FEM SERIES无溢流型快速接头，派克快速接头

泉州市天益机电0595-68253668   蒋女士  企业QQ 3001030018

地址 泉州市丰泽建南花园16-204

带背压释放器 集成模板式
1/8 FEM-121-2FB 450 -- -- G 1/8 19 40 21
1/4 FEM-251-4FB 315 IF2510 RV 315 G 1/4 27 64 30

1/4 FEM-251-4FP-NL 315 -- -- 1/4-18 NPSF 1" 53 30
3/8 FEM-371-6FB 250 IF3810 RV 250 G 3/8 30 71 32
3/8 FEM-371-8FB 250 IF3810-50RV 250 G 1/2 30 73 32
3/8 FEM-371-6FP-NL 250 -- -- 3/8-18 NPSF 1 1/16" 74 32
1/2 FEM-501-8FB 250 IF5010 RV 250 G 1/2 36 76 40
1/2 FEM-501-12FB 250 IF5010-75RV 250 G 3/4 36 80 40
1/2 FEM-501-8FP-NL 250 -- -- 1/2-14 NPSF 1 1/4" 78 40
5/8 FEM-621-12FB 250 IF6310 RV 250 G 3/4 40 82 43
3/4 FEM-751-12FB 250 IF7510 RV 250 G 3/4 46 96 50
3/4 FEM-751-16FB 250 IF7510-100RV 250 G 1 46 102 50
3/4 FEM-751-12FP-NL 250 -- -- 3/4-14 NPSF 1 3/4" 101 50
1 FEM-1001-16FB 200 IF10010 RV 200 G 1 55 105 60

泉州市天益机电0595-68253668  蒋女士  企业QQ 3001030018
1 FEM-1001-20FB 200 IF10010-125RV 200 G 1 1/4 55 106 60
1 FEM-1001-16FP-NL 200 -- -- 1-11 1/2 NPSF 2" 107 58
1/4 FEC-251-4FB 315 G 1/4 27 91 30
3/8 FEC-371-6FB 250 G 3/8 30 99 32
1/2 FEC-501-8FB 250 G 1/2 40 112 43
5/8 FEC-621-12FB 250 G 3/4 40 117 43
3/4 FEC-751-12FB 250 G 3/4 50 130 54
1 FEC-1001-16FB 200 G 1 55 143 60
1 FEC-1001-20FB 200 G 1 1/4 55 146 60
1/4 FEMP-251-4FB 315 G 1/4 27 64 5 15 34
3/8 FEMP-371-6FB 250 G 3/8 30 71 5 15 38
1/2 FEMP-501-8FB 250 G 1/2 36 76 5 15 46
5/8 FEMP-621-12FB 250 G 3/4 40 82 5 15 48
3/4 FEMP-751-12FB 250 G 3/4 46 95 5 15 53
1 FEMP-1001-16FB 200 G 1 55 105 5 15 65

FEM / IF 系列 - 阳接头
带背压释放器 集成模板式 集成模板式带背压释放器
1/8 FEM-122-2FB 450 -- -- G 1/8 17 35 19
1/4 FEM-252-4FB 315 IF2520 RV 315 G 1/4 22 49 37 25
1/4 FEM-252-4FP 315 -- -- 1/4-18 NPSF 1" 44 32 27
3/8 FEM-372-6FB 250 IF3820 RV 250 G 3/8 30 58 42 32
3/8 FEM-372-8FB 250 IF3820-50RV 250 G 1/2 30 60 44 32
3/8 FEM-372-6FP 250 -- -- 3/8-18 NPSF 1 1/16" 63 47 30
1/2 FEM-502-8FB 250 IF5020 RV 250 G 1/2 36 66 49 40
1/2 FEM-502-12FB 250 IF5020-75RV 250 G 3/4 36 70 53 40
1/2 FEM-502-8FP 250 -- -- 1/2-14 NPSF 1 1/4" 71 55 36
5/8 FEM-622-12FB 250 IF6320 RV 250 G 3/4 40 71 84 40
3/4 FEM-752-12FB 250 IF7520 RV 250 G 3/4 46 77 55 50
3/4 FEM-752-16FB 250 IF7520-100RV 250 G 1 46 83 61 50
3/4 FEM-752-12FP 250 -- -- 3/4-14 NPSF 1 3/4" 86 63 50
1 FEM-1002-16FB 200 IF10020 RV 200 G 1 55 89 66 60
1 FEM-1002-20FB 200 IF10020-125RV 200 G 1 1/4 55 90 67 60
1 FEM-1002-16FP 200 -- -- 1-11 1/2 NPSF 2" 98 75 58
1/4 FEC-252-4FB 315 G 1/4 27 74 62 30
3/8 FEC-372-6FB 250 G 3/8 30 87 71 32
1/2 FEC-502-8FB 250 G 1/2 40 98 81 43
5/8 FEC-622-12FB 250 G 3/4 40 101 84 43
3/4 FEC-752-12FB 250 G 3/4 50 114 91 54
1 FEC-1002-16FB 200 G 1 55 126 103 60
1/4 FEMP-252-4FB 315 G 1/4 32 49 5 15 32
3/8 FEMP-372-6FB 250 G 3/8 30 58 5 15 36
1/2 FEMP-502-8FB 250 G 1/2 45 66 5 15 45
5/8 FEMP-622-12FB 250 G 3/4 46 71 5 15 46
3/4 FEMP-752-12FB 250 G 3/4 50 83 5 15 50
1 FEMP-1002-16FB 200 G 1 65 89 5 15 65
1/4 FECP-252-4FB 315 G 1/4 27 74 5 15 34
3/8 FECP-372-6FB 250 G 3/8 30 87 5 15 38
1/2 FECP-502-8FB 250 G 1/2 40 98 5 15 46
5/8 FECP-622-12FB 250 G 3/4 40 101 5 15 46
3/4 FECP-752-12FB 250 G 3/4 50 114 5 15 53
1 FECP-1002-16FB 200 G 1 55 126 5 15 65

FEM / IF 系列 - 防尘盖

泉州市天益机电0595-68253668  蒋女士  企业QQ 3001030018

1/8 IB3826 蓝色橡胶IB2526 蓝色橡胶
1/4 PFE-251-P 黑色橡胶CFE-252-P 黑色橡胶
3/8 PFE-371-P 黑色橡胶CFE-372-P 黑色橡胶
1/2 PFE-501-P 黑色橡胶CFE-502-P 黑色橡胶
5/8 PFE-621-P 黑色橡胶CFE-622-P 黑色橡胶
3/4 PFE-751-P 黑色橡胶CFE-752-P 黑色橡胶
1 PFE-1001-P 黑色橡胶CFE-1002-P 黑色橡胶

FEM / IF 系列 - 阳接头维修包
1/8 IF2300-PSN IF2300-PSV
1/4 IF2500-PSN IF2500-PSV
3/8 IF3800-PSN IF3800-PSV
1/2 IF5000-PSN IF5000-PSV
5/8 IF6300-PSN IF6300-PSV
3/4 IF7500-PSN IF7500-PSV
1 IF10000-PSN IF10000-PSV

FEM-251-4FB FEM-252-4FB 1/4 1/4 315 4565 FEM-371-6FB FEM-372-6FB 3/8 3/8 250 3625 FEM-371-8FB FEM-372-8FB 3/8 1/2 250 3625 FEM-501-8FB FEM-502-8FB 1/2 1/2 250 3625 FEM-501-12FB FEM-502-12FB 1/2 3/4 250 3625
FEM-621-12FB FEM-622-12FB 5/8 3/4 250 3625 FEM-751-16FB FEM-752-16FB 3/4 1 250 3625 FEM-1001-20FB FEM-1002-20FB 1 1.1/4 200 2900  泉州市天益机电0595-68253668  蒋女士  企业QQ 3001030018

FEM-1001-16FO-NL,FEM-1001-16FP-NL,FEM-1002-16FO,FEM-1002-16FP
FEM-251-4FP-NL,FEM-252-4FP,FEM-371-6FP-NL,FEM-371-8FO-NL
FEM-372-6FP,FEM-372-8FO,FEM-501-10BMF-NL,FEM-501-12BMF-NL
FEM-501-12FB-NL,FEM-501-12FO,FEM-501-12FO-NL,FEM-501-8FP
FEM-502-10BMF,FEM-502-12BMF,FEM-502-12FO,FEM-502-8FP
FEM-751-12FO-NL,FEM-751-12FP-NL,FEM-752-12FO,FEM-752-12FP
FEM-251-4FB,FEM-252-4FB,FEM-371-6FB,FEM-371-8FB,FEM-372-6FB
FEM-372-8FB,FEM-501-18MCL,FEM-501-22MCL,FEM-501-8FB
FEM-502-18MCL,FEM-502-22MCL,FEM-502-8FB,FEM-621-12FB,FEM-622-12FB

FEM-371-18MCL FEM-372-18MCL 3/8 12 L 250 3625 FEM-371-22MCL FEM-372-22MCL 3/8 15 L 250 3625 FEM-501-18MCL FEM-502-18MCL 1/2 12 L 250 3625 FEM-501-22MCL FEM-502-22MCL 1/2 15 L 250 3625

1/4 FEM-252-4FP .250-18 NPSF
3/8 FEM-372-6FP .375-18 NPSF
3/8 FEM-372-8FO .750-16 UNF
1/2 FEM-502-8FP .500-14 NPSF
1/2 FEM-502-10FO .875-14 UNF
1/2 FEM-502-10BMS 1.000-14 UNS
1/2 FEM-502-10BMF .875-14 UNF
1/2 FEM-502-12FO 1.062-12 UN
5/8 FEM-622-12FO 1.062-12 UN
3/4 FEM-752-12FP .750-14 NPSF
3/4 FEM-752-12FO 1.062-12 UN
1 FEM-1002-16FP 1.000-11.5 NPSF
1 FEM-1002-16FO 1.312-12 UN
1/4 FEM-251-4FP-NL .250-18 NPSF
3/8 FEM-371-6FP-NL .375-18 NPSF
3/8 FEM-371-8FO-NL .750-16 UNF
1/2 FEM-501-8FP-NL .500-14 NPSF
1/2 FEM-501-10BMS-NL 1.000-14 UNS
1/2 FEM-501-10BMF-NL .875-14 UNF
1/2 FEM-501-10FO-NL .875-14 UNF
1/2 FEM-501-12FO-NL 1.062-12 UN
5/8 FEM-621-12FO-NL 1.062-12 UNF
3/4 FEM-751-12FP-NL .750-14 NPSF
3/4 FEM-751-12FO-NL 1.062-12 UNF
1 FEM-1001-16FP-NL 1.000-11.5 NPSF
1 FEM-1001-16FO-NL 1.312-12 UNF
FEM-1001-20FB PARKER
FEM-1002-20FB PARKER
FEM-251-4FB PARKER
FEM-252-4FB PARKER
FEM-371-16MCL PARKER
FEM-371-18BMCL PARKER
FEM-371-18MCL PARKER
FEM-371-22BMCL PARKER
FEM-371-22MCL PARKER
FEM-371-6FB PARKER
FEM-371-8FB PARKER
FEM-372-16MCL PARKER
FEM-372-18BMCL PARKER
FEM-372-18MCL PARKER
FEM-372-22BMCL PARKER
FEM-372-22MCL PARKER
FEM-372-6FB PARKER
FEM-372-8FB PARKER
FEM-501-12FB PARKER
FEM-501-18MCL PARKER
FEM-501-22MCL PARKER
FEM-502-12FB PARKER
FEM-502-18MCL PARKER
FEM-502-22MCL PARKER
FEM-621-12FB PARKER
FEM-622-12FB PARKER
FEM-751-16FB PARKER
FEM-752-16FB PARKER

泉州市天益机电0595-68253668  蒋女士  企业QQ 3001030018
parker快速接头，Parker FEM SERIES无溢流型快速接头，派克快速接头的设计ISO 16028标准的设计及压力要求。FEM标准件设计还可方便于选择各种阳接头，派克FEM接头设计用于建筑，公用设施及农业设备。如所有派克平齐端面设计一样，这种无溢流型快速接头的特征在于它削除了连接或断开液压附件时出现的液压泄漏和夹气。FEM系列可理想地用于许多其他应用，这类应用的特征是液压泄漏为一关注问题而且与其他制造厂家产品的普遍互换比较重要。阳接头：碳钢；表面处理：表面镀白锌；阀：平齐端面阀机构；密封件：抗爆裂丁晴橡胶

泉州市天益机电0595-68253668  蒋女士  企业QQ 3001030018

parker快速接头，Parker FEM SERIES无溢流型快速接头，派克快速接头主要型号：
FEM-1001-16FO-NL,FEM-1001-16FP-NL,FEM-1002-16FO,FEM-1002-16FP
FEM-251-4FP-NL,FEM-252-4FP,FEM-371-6FP-NL,FEM-371-8FO-NL
FEM-372-6FP,FEM-372-8FO,FEM-501-10BMF-NL,FEM-501-12BMF-NL
FEM-501-12FB-NL,FEM-501-12FO,FEM-501-12FO-NL,FEM-501-8FP
FEM-502-10BMF,FEM-502-12BMF,FEM-502-12FO,FEM-502-8FP
FEM-751-12FO-NL,FEM-751-12FP-NL,FEM-752-12FO,FEM-752-12FP
FEM-251-4FB,FEM-252-4FB,FEM-371-6FB,FEM-371-8FB,FEM-372-6FB
FEM-372-8FB,FEM-501-18MCL,FEM-501-22MCL,FEM-501-8FB
FEM-502-18MCL,FEM-502-22MCL,FEM-502-8FB,FEM-621-12FB,FEM-622-12FB
